MVI56E-GSC PROSOFT Generic ASCII Serial Enhanced Communication Module PROSOFT MVI56E-GSC

MVI56E-GSC PROSOFT Generic ASCII Serial Enhanced Communication Module PROSOFT MVI56E-GSC

MVI56E-GSC

The Generic ASCII Serial Enhanced Communication Modules allow Rockwell Automation ControlLogix Programmable Automation Controllers (PACs) to easily interface with serial devices using non-specific ASCII character text string or byte value serial communication protocols.

MVI56E-GSC enhancements include local and remote diagnostics through the module's Ethernet port, CIPconnect technology for bridging through Rockwell Automation ControlNet and EtherNet/IP networks, and an on-board web server containing status information, module documentation, and sample program files.

The MVI56E-GSC module is a fast and easy way to add two fully configurable serial communication ports to the ControlLogix platform, eliminating the need to use the front port of the processor or to consume valuable processing time sending and receiving serial messages.

The module is a single-slot, backplane-compatible solution. Each port is capable of sending and receiving large ASCII character strings or byte streams of up to 4096 characters or bytes. Many different serial communication devices can be integrated into the ControlLogix platform by building upon the sample ladder logic provided for this module.

Features and Benefits

Specifications

• Backward-compatible with previous MVI56-GSC version
• Single Slot - 1756 ControlLogix backplane compatible
• 10/100 MB Ethernet port for network configuration and diagnostics with Auto Cable Crossover Detection
• User-definable module data memory mapping of up to 5000 16-bit registers
• CIPconnect-enabled network diagnostics and monitoring using ControlLogix 1756-ENxT modules and EtherNet/IP pass-thru communications
• Sample Ladder Logic or Add-On Instruction (AOI) used for data transfers between module and processor and for module configuration
• Internal web page providing access to product documentation, module status, and firmware update software
• 4-character, scrolling LED display of status and diagnostic data in plain English
• ProSoft Discovery Service (PDS) software finds the module on the network and assigns a temporary IP address to facilitate module access

Payment:T/T 100% in Advance

Lead Time : 3-5 Days

Minimum Order Quantity : 1 Piece

Warranty : 1 Year
