Product Details:

Place of Origin: GERMANY
Brand Name: B&R
Certification: CO.CQ
Model Number: 4PP120.1505-31

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: inquiry
Packaging Details: new and original with factory sealed
Delivery Time: today
Payment Terms: T/T
Supply Ability: 10 pieces a day
Contact Now
Detailed Product Description
Manufacture Year: 2016 Con 6DS1311-8AEtrol System: 4PP120.1505-31
Application: Nuclear Power Plant Lead Time: In Stock
Description: B&R Weight: 4lbs



4PP120.1505-31 | B&R | Touch Screen Operator Panel B&R 4PP120.1505-31



4PP120.1505-31  | B&R | Touch Screen Operator Panel B&R  4PP120.1505-31





Device 4PP120.1505-31

Features                                          4PP120.1505-31

Bootloader                                        Automation Runtime

Processor                                         Geode SC2200 266 MHz, MMX compatible

Flash                                                2 MB, onboard, for firmware

Main Memory                                   16 MB DRAM

Graphic Memory                              4 MB shared memory (reserved by the main                                                               memory)

SRAM, 256 KB Onboard,

Battery Backed                                 -

Watchdog, SMC Internal                   -

Power Fail Logic,

SMC 10 ms Buffer Time                    -

Real-time Clock                               Yes, not battery backed

Battery (Lithium, 950mAh,

exchange from outside)                     -

Ethernet

Controller (onboard)                         MacPhyter DP83815 ; 10/100 Mbit/s

Connection                                       RJ 45 twisted pair (10 BaseT / 100 BaseT)

Cabling MacPhyter                           S/STP (category 5)

Compact Flash Slot                          1 slot for type I Compact Flash cards

Serial Interface(COM)                      RS232; modem capable; not electrically                                                                     isolated

USB                                                  2x USB 1.1, connection type A

LEDs                                                1 LED user (green), 1 LED CF (yellow)

Mode/Node Switch                           2 pcs. each 16 digits

aPCI Slots                                         -

Display

Type                                                 TFT

Diagonal                                           15 in

Colors                                               256 Colors

Resolution                                        XGA, 1024 x 768 pixels

Background Lighting

Brightness                                        330 cd/m²

Half Brightness Time                         35,000 hours

Touch Screen

Technology                                        Analog, resistive (3M)

Controller                                           Serial (Hampshire)

Front

Frame                                                Aluminum anodized

Mylar                                                  Polyester

Gasket                                               Flat gasket around display front

Keys

Function Keys                                   -

Function Keys with LEDs                  -

Softkeys                                            -

Softkeys with LEDs                           -

System Keys                                     -

System Keys with LEDs                    -

Supply Voltage                                 24 VDC ± 25%, not electrically isolated
