3500/22M Bently Nevada Transient Data Interface Module Bently Nevada 3500/22M 288055-01
  • 3500/22M Bently Nevada Transient Data Interface Module Bently Nevada 3500/22M  288055-01

3500/22M Bently Nevada Transient Data Interface Module Bently Nevada 3500/22M 288055-01

Place of Origin USA
Brand Name Bently Nevada
Certification CO.CQ
Model Number 3500/22M 288055-01
Product Details
Manufacture Year:
2016
Con 6DS1311-8AEtrol System:
3500/22M 288055-01
Application:
Nuclear Power Plant
Lead Time:
In Stock
Description:
Bently Nevada
Weight:
4lbs
High Light:

bently nevada 3500

,

bently nevada vibration monitoring system

Payment & Shipping Terms
Minimum Order Quantity
1
Price
inquiry
Packaging Details
new and original with factory sealed
Delivery Time
today
Payment Terms
T/T
Supply Ability
10 pieces a day
Product Description

3500/22M Bently Nevada Transient Data Interface Module Bently Nevada 3500/22M 288055-01



3500/22M Transient Data Interface Module

Bently Nevada* Asset Condition Monitoring





PRODUCT NAME: 3500/22M 288055-01

3500/22M Bently Nevada Transient Data Interface Module Bently Nevada 3500/22M  288055-01 0



Description

The 3500/22M Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1* Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.

The TDI resides in the slot adjacent to the power supplies of a 3500 rack. It interfaces with M series monitors (3500/40M, 3500/42M, etc.) to continuously collect steady state and transient dynamic (waveform) data and pass this data through an Ethernet link to the host software. Refer to the Compatibility section at the end of this document for more information.

Static data capture capability is standard with the TDI. However, using an optional Channel Enabling Disk will allow the TDI to capture dynamic and high-resolution transient data as well. The TDI incorporates the communication processor function within the 3500 rack.

Although the TDI provides certain functions common to the entire rack, it is not part of the critical monitoring path and has no effect on the proper, normal operation of the overall monitor system for automatic machinery protection. Every 3500 rack requires one TDI or RIM, which always occupies Slot 1 (next to the power supplies).



NOTICE

1. Payment: T/T

2. Lead Time: 3-5 Days

3. One Year Warranty.

4. Shipment by DHL,UPS,FEDEX,ARAMAX,TNT,etc



3500/22M Bently Nevada Transient Data Interface Module Bently Nevada 3500/22M  288055-01 1
