SIEMENS 6ES7 431- 1KF10-0AB0
SM 431 analog input module


Part Number

6ES7 431- 1KF10-0AB0

Model Type

SM 431 analog input module

Manufacturer(s)
Siemens


Estimated Shipping Size
Dimensions: 25 mm*290 mm*210 mm
Weight: 500 g

SIMATIC S7-400, analog input SM 431, non-isolated 16 AI, resolution 13 bit, +/-10 V, +/-20 mA, 4 - 20 mA 20 ms conversion time
SM 431 ANALOG INPUT MODULE
Function
Analog input modules convert analog signals from the process into digital values for internal processing within the S7- 400.
The modules feature the following: §

• Resolution from 13 to 16 bit §
• Different measurement ranges §
• Alarm functionality §
• Diagnostics

25 mm*290 mm*210 mm 500 g
Rated value (DC)                                            24 V; Only required for supplying 2- wire transmitters
from load voltage L+ (without load), max.      200 mA
from backplane bus 5 V DC, max.                 600 mA
Power loss, type                                             3.5 W
Number of analog inputs                                8
permissible input current                                40 mA
