About the Product

The Pacific Scientific® 5645 Microstep Indexer/Drive combines a high-performance, bipolar chopper drive with a Pacific Scientific StepperBASIC™ programmable indexer for stepper motor motion control.

Drive features

The output current of the 5645 is switch selectable for current of 5.0 to 8.0 amps/phase RMS (7.1 to 11.3 amps peak) with a 160-volt nominal dc bus. The 5645 is factory preset at 5.0 amps/phase RMS.

Bipolar chopper drive -controls motor current at 20 kHz chopper frequency

Internal power supplies - operate from the 120-volt ac input. The main motor supply consists of a full wave bridge rectifier into a capacitive input filter with in-rush current limiting

Shunt regulator circuitry -protects the drive by removing energy from the supply if the dc bus voltage exceeds 200 volts. This feature protects the circuitry from excessive voltage that may be generated under certain motor deceleration conditions.

Short circuit protection circuitry - latches the drive off and lights the POWER FAULT LED if a short circuit occurs on the motor outputs. After removing the short circuit, reset the 5645 by switching the power Off and then On.

Status indicators - LEDs for operation and troubleshooting information.
