SITRANS FU E950 | SIEMENS SITRANS FU E950 siemens energy calculator

The battery or mains powered SITRANS FUE950 is a universal custody transfer approved energy calculator. It is designed for use in hot water, chilled water and cooling/heating applications.

The calculator has a modular construction which means that it can be fitted with optional output modules when it is ordered. These include a pulse output, pulse input, current output and an M-Bus add-on module. If needed, the necessary temperature sensor pair and pockets can be ordered along with the calculator.

The SITRANS FUE950 can be used with SITRANS FUS380, SITRANS FUE380, SITRANS F M MAG 5000, SITRANS F M MAG 6000, SITRANS F M MAG 8000 and SITRANS FS220.

PRODUCT DATASHEET

Meassuring range

Qp ≤ 360000 m³/h (600000 GPM)
P ≤ 15000000 kW

Accuracy

EN1434 Class 3, typical ±(0.5 + 3K/ΔΘ) [%]

Input / output

Input:

1 Pulse of flowmeter (always included)

2 Temperature input as PT100/500,

2 or 4-wire (always included)

2 Pulse input (optional)

Output:

2 Pulse or status (optional)

1 M-Bus (optional)

1 RS 232 M-Bus protocol (optional)

1 RS485 M-Bus protocol (optional)

2 current (4-20mA , passive) (optional)

Display

8-digit LCD display with associated pictograms/symbols

Enclosure

IP54 (in accordance with IEC 529)

Power Supply

Battery (3.6V Lithium D-cell type)
230 V a.c.
24 V a.c.

Temperature input

From -20 to 190 °C (-4 to 374 °F)

Ambient temperature

From 0 to 55 °C (32 to 131 °F)

Approvals

MID (EN1434, heating) and PTB K7.2 (cooling)

Benefits

MID directive approval for custody transfer for water energy metering

Cooling approval (according national German PTB K7.2 standard)

Suitable for 2 and 4 wire temperature sensor connection

Delivered with heat-/cooling approved PT500 sensor set (incl. sensor pockets)

Optical M-Bus data reading in accordance with EN 1434

Instantaneous values for energy and volume flow

Flexible input / output option modules

Long battery lifetime (up to 16 years)

Option for 2 current outputs (4 ... 20mA, passive)
