2711P-T10C4A8 2711PT10C4A8 AB AB PanelView Plus Terminal
⇒ Click here for good price 2711P-T10C4A8
Brand/Manufacturer | AB /USA |
Part Number |
2711P-T10C4A8 |
Alternate Part Number | 2711P-T10C4A8 |
Description | MOTOR SERVO |
Dimennsions |
34x38.5x18cm |
Weight | 3.4kg |
Contact Us
Email: miya@mvme.cn (CLICK)
QQ: 2851195450
Tel: 86-18020776792(CLICK)
Skype:miyazheng520(CLICK)
Product Details
The AB 2711P-T10C4A8 PanelView Plus 6 Terminal is a Human-Module Interface (HMI) with an interactive graphics display that makes controlling a machine easy. The 2711P-T10C4A8 provides users with flexible configuration through the separate logic module and display module, and the communication modules. It arrives preloaded and activated with FactoryTalk View Machine Edition software and FactoryTalk ViewPoint software. Various HMI applications can also be developed with the FactoryTalk View Studio software.
The 2711P-T10C4A8 Terminal has a 10.4-inch TFT display with resistive touchscreen input. The native resolution is 640 x 480 pixels with 18-bit color graphics. It has 512 MB of RAM and 512 MB of nonvolatile memory for data storage. The 2711P-T10C4A8 weighs 8 pounds and measures 16 x 14 x 8 inches. It requires an input voltage of 100 to 240 Volts AC at 50 to 60 Hertz with a 160 VA maximum power consumption. For communication, it has Ethernet and RS-232 serial ports with optional DH-485, DH+, and ControlNet module ports. The 2711P-T10C4A8 also has 2 USB ports for connecting external devices such as keyboards and flash drives. This 2711P-T10C4A8 PanelView Plus 6 allows the user to connect using FactoryTalk View Machine Edition software and an Ethernet and RS-232 communication port with a 2711-NC13 communication cable(s). The user is able to control the 2711P-T10C4A8 operator interface by utilizing the touchscreen to input information and data.
