ABB Module CI532V02 3BSE003827R1 ABB CI532V02 Bus Card Communication Interface 50% off

ABB Module CI532V02 3BSE003827R1 ABB CI532V02 Bus Card Communication Interface 50% off

Product Description:

The procedure is repeated for the other input and output channels with each successive pressing and releasing of the test button.After accessing the last channel, another pressing of thetest botton initiates an LED test. All LEDs must light upFollowing that, the position of the address switch is displayed
by LEDs 00 to 07 for about 3 seconds which was set by module 07 DC 92 during the initialization. In this
case LED 00 shows the setting of switch 1 (LEDs 0...7 are assigned to switches 1...8 ).The error messages at the I/O module and at the central control unit go out as soon as the errors have been corrected,no new errors exist and the error correction has been acknowledged.Acknowledging an error after error correction:by pressing the test button for about 5 seconds or by the PLC program, or by the PC.

Related Product Recommendation:

Product's Character:

An address must be set for each module to enable the central unit to correctly access the inputs and outputs.A detailed description about "Addressing" can be found in the chapter "Addressing" for the central processing unit and coupler.The address setting is accomplished with the DIL switch located under the slide cover on the right side of the module housing.When using cental units 07 KR 91 or 07 KT 9x as bus
master, the following possibilities (address assignments)are offered, depending on the setting of the address DIL switch  Item n in the table designates the module address that can be set with the address DIL switch with switches 2...7. When using 07 KR 91 / 07 KT 9x as bus master, we recommend to use even-numbered module addresses (08,10, 12......60).In this setting, (DIL switch 1 in OFF position = factory setting) the module occupies two addresses for inputs and outputs.
