ABB Module CI540 3BSE001077R1 ABB CI540 COM INTERFACE Online hot welcome to buy

ABB Module CI540 3BSE001077R1 ABB CI540 COM INTERFACE Online hot welcome to buy

Product Description:

Electrical isolation CS31 system bus from the rest of the unit inputs/outputs group from group, all groups from the rest of the unit Supply of the I/O groups each group is supplied individually, see Fig. 4.8-2
Number of interfaces 1 CS31 system bus interface Address setting Coding switch located under the slide cover at the right side of the housing Diagnosis see chapter "Diagnosis and display" Operation and error displays a total of 33 LEDs Technical data of the I/O channels as binary inputNumber of channels per unit 32 Division of channels into groups 4 groups with 8 channels each,channels En,00...En,07 and En,08...En,15 channels En+1,00...En+1,07 and En+1,08...En+1,15Reference potential for inputs ZP0, ZP1, ZP2 and ZP3

Related Product Recommendation:

Product's Character:

Due to the direct connection to the output, the demagnetizing varistor is also effective at the input when disconnecting inductive loads (see figure). This is why the difference between UPx and the input signal may not exceed the clamp voltage of the varistor. The varistor limits the voltage to approx. 36 V. Following this, the input voltage must range from - 12 V to + 30 V when UPx = 24 V and from - 6 V to + 30 V when UPx = 30 V.When all 8 channels of the group are used as inputs and terminal UPx is not wired-up, there are no restrictions to the input signals. In this case, the input voltage can range from - 30 V to + 30 V. The following figure shows the circuit arrangement of a digital input/output.

The use of the product:
