ABB Module DSMB176 57960001-HX ABB DSMB176 MEMORY MODULE affordable price

ABB Module DSMB176 57960001-HX ABB DSMB176 MEMORY MODULE affordable price

Product Description:

 Independent of the selected operating mode, the following features are valid: The pulses at the counter input or the evaluated signals at tracks A and B in case of connection of incremental
position sensors are counted. The maximum counting frequency is 50 kHz. The counter uses the terminals 2 (E 62,00) and 3 (E 62,01) as fast inputs and, in one operating mode, also the output terminal 46 (A 62,00). In order to make all binary inputs and outputs available for other purposes than counting, it is possible, to disable the 07 KT 97’s counting function.The counter can count upwards in all operating modes, in some modes it also can count dounwards. The counting range is from –32768 to +32767 or from 8000H

Related Product Recommendation:

Product's Character:

In general, the technical system data listed under ”System data and system configuration” in chapter 1 of volume 2 ofthe Advant Controller 31 system description are valid. Additional data or data which are different from the system dataare listed as follows.(of the 07 KT 97 and of the communication
processor) are assembled by means of a snap-on connection.The SmartMedia Card serves for storing data up to 2 MB not being lost over an power OFF/ON cycle. It is used in the 07 KT 97 basic unit. It is recommended only to use ABB-proven SmartMedia Cards. Field of application Storing and loading of PLC programs Storing and loading of user data  there are 250 data segments with 128 blocks
each available (1 block = 32 words). Loading of firmware updates

The use of the product:
