ABB Module DSQC227 YB560103-BK ABB DSQC227 ROBOT SERVO AMP affordable price

ABB Module DSQC227 YB560103-BK ABB DSQC227 ROBOT SERVO AMP affordable price

Product Description:

Resolution in the PLC system:The measured values are converted with a resolution of 12 bits, i.e. 11 bits plus sign for voltage and 12 bits without sign for current. The ranges 0...5 V und ±5 V are converted
with 10 bits plus sign. Examples: Measuring range Range of numbers 10 V...0...10 V 32760D....0....32760D 8008H...0000...7FF8H 20 mA 0...32760D 7FF8H Further details can be found in volume 2, chapter 5.1 "General information for the use of analog inputs and outputs". In order to make sure, that unused input channels have a defined 0V level, they may be shorted to AGND. Unused
inputs must be configured with "unused". The relationship between the analog input signals and the
converted numbers is illustrated in the following figures.

Related Product Recommendation:

Product's Character:

If all of the 8 channels of the group are used as inputs, and if in addition the UP5 terminal is left unconnected, no restrictions exist for the inputs. The input signal voltages then may be within -30 V and 30 V. There is no restriction for the input/output group concerning its safety against reversed polarity.System constants. If no battery is effective or if the system constants are in their default values (factory settings), all of the above mentioned data areas are completely set to 0 after power OFF/ON.  Reactions on errors of error class 3 The user can configure whether or not the user program is to be aborted automatically, if an class 3 error occurs, see chapter B7 (Appendix), System constants.

The use of the product:
