ABB Module DSQC662 3HAC026254-001 ABB DSQC662 3HAC026254-001 DSQC 662 Power Module Highest version

ABB Module DSQC662 3HAC026254-001 ABB DSQC662 3HAC026254-001 DSQC 662 Power Module Highest version

Product Description:

If the output is to use as a normal digital output, it has to be made sure, that the high-speed counter is not configured to the operating modes 1 or 2 (see also the chapter "High-speed counter"). Features of the digital inputs/outputs:The 8 digital inputs/outputs are arranged in one group.The group as a whole is electrically isolated from the rest of the device.The inputs/outputs can be used individually as input,
output or re-readable output. If the terminals are used as digital inputs, the input signal delay can be configured to 7 ms (default) or to 1 ms. The configuration is performed by setting certain
bits in the system constant KW 85,01 as follows

Related Product Recommendation:

Product's Character:

 The red LED Ovl. goes out when the overloaded output is switched on again automatically. The acknowledgement of the error message, i.e. the resetting of the error flags, is carried out according to
chapter B4.8 (Appendix), Acknowledgement of error messages in the basic unit.The outputs are safe against reverse polarity and forced supply of 24 V DC.Use of the digital output signal at the terminal 46
(A 62,00) for the high-speed counter The output A 62,00 can be assigned to the internal highspeed
counter by configuration. If the counter is used in the operating modes 1 or 2 (up-counter), the output A 62,00 is only available for the counter.

The use of the product:
