ABB Module DSQC664 3HAC030923-001 ABB DSQC664 3HAC030923-001 DSQC 664 axis drive 50% discount

Product Description

ABB Module DSQC664 3HAC030923-001 ABB DSQC664 3HAC030923-001 DSQC 664 axis drive 50% discount

Product Description:

If the terminals are used as digital outputs, the output signals "1" are individually monitored by the re-readable input. If the output status is wrong, an overall error message is generated for the involved output group.The error is displayed by the red LED Ovl. and by error flags of the PLC then.The error could have been caused by overload, shortcircuit or missing supply voltage UP5/ZP5.The technical specifications are the same as with the other digital inputs and outputs.The technical specifications of the inputs are the same with the other digital inputs, but with the following exception:Caused by the direct electrical connection with the output, the varistor for demagnetization of inductive loads (see figure above) is also in effect at the input.Therefore, the voltage difference between UP5 and
the input signal must not be greater than the limit voltage of the varistor.

Related Product Recommendation:

Product's Character:

 The red LED Ovl. goes out when the overloaded output is switched on again automatically. The acknowledgement of the error message, i.e. the resetting of the error flags, is carried out according to
chapter B4.8 (Appendix), Acknowledgement of error messages in the basic unit.The outputs are safe against reverse polarity and forced supply of 24 V DC.Use of the digital output signal at the terminal 46
(A 62,00) for the high-speed counter The output A 62,00 can be assigned to the internal highspeed
counter by configuration. If the counter is used in the operating modes 1 or 2 (up-counter), the output A 62,00 is only available for the counter.
