Product Description:

Never try to charge a battery! Danger of overheating and explosion.Replace the battery only with the supply voltage switched on! Otherwise you risk data being lost. Dispose of battery environmentally consciously!If no battery is inserted or if the battery is exhausted,
the red LED "Battery" lights up. As long as there is a supply voltage available, there is no more load on the battery other than its own leakage current.The following handling notes have to be observed:
Use only lithium batteries approved by ABB.Replace the battery by a new one at the end of its life. Never short-circuit the battery!There is danger of overheating and explosion. Avoid accidental short-circuits, therefore do not store batteries in metallic containers or boxes and do not bring them into contact with metallic surfaces.

Related Product Recommendation:

Product's Character:

In case of voltage outputs the max. output current is 3 mA. The output is short-circuit proof.
In case of current outputs, the range of permissible output load resistors is 0...500 Ω. If in case of an error the outputs are switched off, this means the following: Configuration ±10 V 0 V Configuration 0...20 mA 0 mA Configuration 4...20 mA 0 mA. The relationship between the numerical values and the
analog values given in figure 4-19 (analog inputs) is also
valid for the analog outputs. In this way the correct measurement will succeed after the current has reached a normal value again.The trigger of the self-protecting mechanism is displayed
by the red LED Ovl as long as the overload is present. In the PLC system an error message is then stored (FK4,error number 4).The open-circuit monitoring begins below ca. 3 mA.
