ABB Module IMDSI14 ABB IMDS-I14 ABB IMDS I14 Digital Input Module 12 month warranty
Product Description:
The overflow numerical value of +32767. If the measured value is below the range, the underflow numerical value of -32767 is set. The input impedance is ca. 330 Ω. The current input has
a self-protecting mechanism. If the input current gets too high, the shunt is switched off and the value for range overflow is generated. About every second, the unit tries to switch on the shunt again. In this way the correct measurement will succeed after the current has reached a normal value again.
The trigger of the self-protecting mechanism is displayed by the red LED Ovl as long as the overload is present. In the PLC system an error message is then stored (FK4, error number 4).
