ABB Module IMFCS01 ABB IMFCS-01 ABB IMFCS 01 SLAVE MODULE BOARD affordable price

ABB Module IMFCS01 ABB IMFCS-01 ABB IMFCS 01 SLAVE MODULE BOARD affordable price

Product Description:

The 07 KT 94 unit linearizes the Pt100 characteristic. Temperatures that exceed the measuring range cause the overflow numerical value of +32767. If the measured value is below the range, the underflow numerical value of -32767 is set. In case of a detected open-circuit the numerical value of +32767 is set. If the sensor is short-circuited, the numerical value of -32767 is set. If the open-circuit or short-circuit monitoring is configured, the detected error is displayed by the red LED Ovl as long as it is present. In the PLC system an error message is stored (FK4, error number 9).In order to avoid error messages with unused analog inputs, it is useful, not to configure this channels for Pt100.The analog outputs can be configured individually in a lot of different operating modes. The configuration is performed by setting certain bits in the system constants KW 88,00 to KW 88,03 as follows

Related Product Recommendation:

Product's Character:

In case of voltage outputs the max. output current is 3 mA. The output is short-circuit proof. In case of current outputs, the range of permissible output load resistors is 0...500 Ω. If in case of an error the
outputs are switched off, this means the following: Configuration ±10 V 0 V Configuration 0...20 mA 0 mA
Configuration 4...20 mA 0 mA. The relationship between the numerical values and the analog values given in figure 4-19 (analog inputs) is also valid for the analog outputs.7 V as signal 1. The input impedance in this operating mode is about 4 kW. Terminal M is the reference potential.The input signal delay is 7 ms. It cannot be configured. The inputs are not electrically isolated.
