Redundant Power Supply Modules

The Chassis Series-A power supply provides 24 Vdc, 5 Vdc, 3.3 Vdc, and 1.2 Vdc. Each module that is inserted into the chassis will consume a portion of the available power. The user must ensure that the planned configuration and mix of modules does not exceed the capability of the power supply. See power consumption section “Module Power Consumption Data”.

Input Voltage Range                    16 – 32 VDC

Input Power                                 110 W (estimated)

Maximum Inrush Current             30 A @ 19 – 32 VDC

Frequency Range                        DC

Total power output maximum, watts           75 W @ 60 C

Input Power Wiring                                     #14 AWG (1.4 mm)

Annunciation User Connection2                 Solid state relay rated for 120 VAC/DC at 100ma maximum

Dimensions (L x D x H)                              14.4 x 13.7 x 17.5 cm (5.67 x 5.39 x 6.89 in)

Weight – Approximate                                1.1 kg (2.5 lb.)

Redundant Power Supply Cable Model (3ft)               TC-RPSC03 (one required per power supply)

Power Supply Cable Weight – Approximate                0.57 kg (1.25 lb.)

Location3                                                                     Upright mounting, typically above/below chassis to be                                                                                       powered.

1.The combination of all output power (5 V backplane, 24 V backplane,

3.3 V backplane and 1.2 V backplane) cannot exceed 75 W.

2. In order to pass certain input power surge testing for CE certification, the length of the wiring from this relay must be limited to ten (10) meters.

3. It is not recommended to mount the power supply above/below its partner power supply as this could create ambient temperatures that are greater than 60 C within 1.0 inch of the bottom of the power supply.
