AB MicroLogix 1500 Processor Unit 1764-LSP AB 1764-LSP


Miya(manager)
Email:miya@mvme.cn
Skype:miyazheng520
QQ :2851195450
Tel:0592-5087576
86-18020776792







Product Name:  AB 1764-LSP

General Specifications

About 1764-LSP

The AB 1764-LSP is a standard processor unit in the MicroLogix 1500 Programmable Controller series. With its 7K user program capacity, it offers significant controller memory solutions to a variety of applications. This memory size is the total of the combined 3.65 KB User Program and 4 KB User Data. These program and data file sizes are user-configurable with a maximum user data capacity of 4K words. The processor memory also stores function files that are user-specified and are used as configuration data for system resources.
The 1764-LSP MicroLogix 1500 Processor has approximately 1 ms program execution time for a 1K-word program (including counter, bit, math instructions, and timer). Programs are created using a Windows-based programming software – the RSLogix 500. Long-integer data files (32-bit signed integer, ±2 billion) can be created for use with embedded high-speed I/O and math instructions. Floating point data files can also be developed, each of which contains a maximum of 256 IEEE-754 floating point data elements.
The 1764-LSP Processor features one non-isolated RS-232-C port with ASCII, DF1 half-duplex, DF1 full duplex, DH-485, and Modbus protocols. It has two built-in Trim Potentiometers with a digital output range of 0-250 volts. These 3/4-turn analog potentiometers allow easy and quick adjustment of counters, set points, and timers. The 1764-LSP also provides an interface to the memory, real-time clock, and DAT modules. The 1764-LSP can be installed with the following bases 1764-24AWA, 1764-24BWA, and the 1764-28BXB. This processor can have the following real time clocks and memory modules installed: 1764-MM1, 1764-MM2, 1764-MM3, 1764-MM1RTC, 1764-MM2RTC, 1764-MM3RTC, 1764-RTC. The MicroLogix 1500 RTC modules come with a battery installed that keeps time. Fault codes for the 1764-LSP can be found in the manual for troubleshooting and set up.

A controller is composed of a processor (1764-LSP or enhanced 1764-LRP with RS-232 port) and one of the base units listed below. The FET transistor outputs are available on the 1764-28BXB base only


The MicroLogix 1500 can be connected to a personal computer. It can also be connected to the DH-485 network using an Advanced Interface Converter (1761-NET-AIC), to an Ethernet network using an Ethernet Interface (1761-NET-ENI), or to a DeviceNet™ network through the DeviceNet Scanner module (1769-SDN). The controller can also be connected to Modbus™ SCADA networks as an RTU slave. See Communication Connections on page 4-1 for more information on connecting to the available communication options. The 1764-LRP processor provides an additional communication port. Each of the communications ports can be independently configured for any supported communication protocol. (Channel 0 is on the base unit and Channel 1 is on the 1764-LRP processor.)
