Description And Features

The Siemens 6ES7132-4BB00-0AA0 is a high-performance digital output module designed for the Siemens SIMATIC S7-1200

PLC system, widely used in industrial automation. This module provides 16 digital output channels with 24V DC, offering a

maximum output current of 0.5A per channel and up to 8A for each group of 8 channels. It features electrical isolation, integrated

diagnostics, and real-time monitoring of output signals, enabling efficient troubleshooting and system optimization. The module

has dimensions of 40mm (width) x 120mm (height) x 75mm (depth) and an IP20 protection rating, making it suitable for various

industrial environments. Additionally, the 6ES7132-4BB00-0AA0 is fully compatible with the Siemens S7-1200 PLC system and

supports DIN rail mounting for secure installation and operation.

16 Digital Output Channels: Offers 16 individual 24V DC digital outputs for controlling various devices

such as relays, actuators, and other digital components.

High Current Capacity: Each output channel can handle up to 0.5A, with a total current capacity of up to

8A for every group of 8 channels.

Electrical Isolation: Provides electrical isolation between the output channels and the PLC system, ensuring

protection and minimizing the risk of electrical interference.

Integrated Diagnostics: Built-in diagnostic capabilities for real-time monitoring of output status, enabling

faster fault detection and improved system maintenance.

Wide Operating Voltage Range: Operates within a voltage range of 20.4V to 28.8V DC, ensuring reliable

performance under varying electrical conditions.

Compact Design: The module is designed with compact dimensions (40mm x 120mm x 75mm), making it

suitable for installations in limited space environments.

IP20 Protection Rating: Offers protection against dust and solid particles, making it suitable for industrial

control panels and machinery.

Frequently Asked Questions About 6ES7132-4BB00-0AA0

Q:What is the Siemens 6ES7132-4BB00-0AA0?

A:The Siemens 6ES7132-4BB00-0AA0 is a digital output module designed for use with the Siemens SIMATIC S7-1200 PLC system. It

provides 16 digital output channels with a 24V DC signal, ideal for controlling devices like relays and actuators.

Q:How many output channels does this module have?

A:The module features 16 digital output channels.

Q:What is the current capacity of each output channel?

A:Each output channel can handle a maximum current of 0.5A, with up to 8A total for each group of 8 channels.
