ABB Module AX645 3BHB001914R1 3BHB001914R0001 ABB AX645 ANALOG I/O MODULE New foreign imports
Product Description:
Technical data of analog inputs Number of channels per module, oper. mode"12 bits" 8 Number of channels per module, oper. mode "8 bits" up to 16 Configurability oper. mode "12 bits" ±10 V, 0...20 mA (each channel can be configured individually) Configurability oper. mode "8 bits" 0...10 V, 0...20 mA (channels can be configured in pairs) Signalization of input signals see diagnosis Input resistance per channel voltage input > 100 kΩ current input approx. 330 Ω The current input has a self-protecting feature. If the current gets too high, the current input shunt is switched off and the value for "overflow" is output. Re-activation is attempted again in increments of approx. 1 second to facilitate the correct measurement as soon as the current regains acceptable limits.Time constant of the input filter 470 μs for voltage,100 μs for current
Related Product Recommendation:
| 3BHE024577R0101 PP C907 BE |
DSTD132 5716001-FX |
MM21 MM 21 |
| 3BSE001245R1 3BSC640008R1 |
DSTD150A 57160001-UH |
MPRC 086349-002 |
| 3BSE003879R1 |
DSTX120 57160001-MA |
MV03 MV 03 |
| 3BSE011316R1 SDCS-PIN-52 |
ECC 086387-001 |
MZ03 MZ 03 |
| BRC100 BRC-100 P-HC-BRC-10000000 |
ECZ FPR3700001R0001 |
NAIO-01 |
| BRC300 PHCBRC30000000 |
EL3020 |
NAOM01 |
| C100/0100/STD |
GJR2370500R2 |
NGDR-02C |
| C1900/0263/0260A C1900/0263 |
GJV3072403R1 07KR264DR1 |
NISA-03 |
| C1900/0363 C1900/0363/0360A |
GJV3074353R1 07EA63R1 |
NTAC-02 |
| C300/0010/STD |
HS01 HS 01 |
NTAI05 |
| CI520V1 3BSE012869R1 |
ICMK14N1 1SBP260052R1001 |
NTAI06 |
| CI522 3BSE012790R1 |
ICSA04B5 FPR3341501R1042 |
NTCL01 |
| CI522A 3BSE018283R1 |
ICSE08B5 FPR3346501R1012 |
NTCL01-A |
| CI526 3BSE006085R1 |
IDS-DTU51 |
NTCS04 |
| AX460 |
IMASI03 |
NTDI0-A |
| AX521 1SAP250100R0001 |
IMASI23 |
NTDI01 |
| AX645 3BHB001914R1 3BHB001914R0001 |
IMASO11 |
NTRO02 NTRO02-A |
| BRC-100 P-HC-BRC-10000000 |
IMDSI14 |
NTRO02-A |
| 07KT98 GJR5253100R0270 |
IMDSI22 |
NTRO02-A NTRO02 |
| 07KT98 WT98 |
IMDSO14 |
PAB02 |
| 07MK92 GATS110098R0161 |
IMDSO14 IMDS014 |
PCU-03 |
| 07MK92 GJR5253300R1161 |
IMFCS01 |
PE1364B |
| 07NG61R1 GJV3074311R1 |
IMFEC12 |
PHARPS32200000 |
| 07NG63R1 GJV3074313R1 |
IMMPI01 |
PHARPS62200000 |
| 07PS62R2 GJV3074332R2 |
IMRIO02 |
PHARPSPEP11013 |
| 07SK90R1 GJR5250200R0001 |
IMSED01 |
PM150V08 3BSE003641R1 |
| 07ZE61R302 GJV3074321R302 |
IMSET01 |
PM253V01 |
| 07ZE63R302 GJV3074323R302 |
INFI90 INFI 90 |
PM510 3BSE000270R1 |
| 086363-002 OSPS2 |
INICT03A |
PM511V08 3BSE011180R1 |
Product's Character:
Diagnosis see chapter Operation and error displays a total of 17 LEDs,see chapter "Diagnosis and displays"Method of connections removable screw-type terminal blocks supply terminals, CS31 system bus max. 1 x 2.5 mm2 or max. 2 x 1.5 mm2 all other terminals max. 1 x 1.5 mm2 Max. length of the analog cables,two-core shielded and cross section > 0.5 mm2 100 m Conversion error of the analog values (non-linearity, factory calibration and resolution) typ. 0.5 %, max. 1 %Max. permissible potential difference between terminal M (minus of the supply voltage) and terminals AGND (minus of analog inputs and outputs) ± 1 V Common reference potential for all analog signals AGND (minus terminal of analog inputs and outputs) Electrical isolation of analog signals
The use of the product:
1.petrochemical,
2.We keep more than 10 thousands Transistors in warehouse, it could cut lead time of most items.
3. textile printing and dyeing,
Product's advantages:
1.We keep more than 10 thousands Transistors in warehouse, it could cut lead time of most items
2.Avoid unplanned downtime
3.emission reduction
Our advantages:
Distribution of various brands and specifications of a total of more than 300,000 kinds, and to business mode of operation, to reduce intermediate links for customers in the first time procurement to provide 'safe and efficient' logistics supply system.
We focus on providing customers with cost-effective industrial automation components to help customers improve return on investment, and we in the industrial control and electrical automation spare parts sales have a strong competitive position.
Frequently Asked Questions:
1.Q: Can you provide discount ?
A: Yes, we are glad to offer you dicount if you order more than 1 piece .
2.Q:How about the payment terms ?
A:We frequently use T/T
3.Q:What about your shipping terms ?
A: We can ship by DHL,UPS,FEDEX,ARAMAX,TNT,and so on
