ABB Module SNAT633PAC SNAT 633 PAC 61049444 ABB SNAT633PAC AMPLIFIER BOARD High reliability

Product Description

ABB Module SNAT633PAC SNAT 633 PAC 61049444 ABB SNAT633PAC AMPLIFIER BOARD High reliability

Product Description:

The technical specifications of the inputs are the same with the other digital inputs, but with the following
exception: Caused by the direct electrical connection with the output, the varistor for demagnetization of inductive loads (see figure above) is also in effect at the input. Therefore, the voltage difference between UP5 and the input signal must not be greater than the limit voltage
of the varistor.If the counter is used in the operating modes 1 or 2 (up-counter), the output A 62,00 is only available for the counter. If the output is to use as a normal digital output, it has to
be made sure, that the high-speed counter is not configured to the operating modes 1 or 2 (see also the chapter "High-speed counter").

Related Product Recommendation:

Product's Character:

The 8 digital inputs/outputs are arranged in one group.The group as a whole is electrically isolated from the rest of the device.The inputs/outputs can be used individually as input, output or re-readable output.If the terminals are used as digital inputs, the input signal delay can be configured to 7 ms (default) or to 1 ms (see "System technology"). If the terminals are used as digital outputs, the output
signals "1" are individually monitored by the re-readable input. If the output status is wrong, an overall error message is generated for the involved output group.The error is displayed by the red LED Ovl. and by error flags of the PLC then. The error could have been caused by overload, short-circuit or missing supply voltage UP5/ZP5. The technical specifications of the outputs are the same as with the other digital outputs.
