ABB Module XN06 XN 06 ABB XN06XN06 NUMBER PLATE New Sealed

ABB Module XN06 XN 06 ABB XN06XN06 NUMBER PLATE New Sealed

Product Description:

The red LED Ovl. goes out when the overloaded output is switched on again automatically.
The acknowledgement of the error message, i.e. the resetting of the error flags, is carried out according to chapter B4.8 (Appendix), Acknowledgement of error messages in the basic unit.The outputs are safe against reverse polarity and forced supply of 24 V DC. Use of the digital output signal at the terminal 46
(A 62,00) for the high-speed counter The output A 62,00 can be assigned to the internal highspeed
counter by configuration. If the counter is used in the operating modes 1 or 2 (up-counter), the output A 62,00 is only available for the counter. If the output is to use as a normal digital output, it has to
be made sure, that the high-speed counter is not configured to the operating modes 1 or 2 (see also the chapter "High-speed counter").

Related Product Recommendation:

Product's Character:

Features of the digital outputs:The 16 digital outputs are arranged in two groups of 8 outputs each. The two groups are electrically isolated from each other.The outputs can be loaded with a rated current of
500 mA. Each group as a whole is electrically isolated from the rest of the device.The outputs employ semiconductors and are shortcircuit and overload-proof.The outputs are automatically switched off in case of overload or short-circuit.An overall error message indicates whether a shortcircuit or an overload has occurred on a output group.The overload is displayed by the red LED Ovl. and via error flags in the PLC. The red LED Ovl. goes out when the overloaded output is switched on again automatically.The outputs are safe against reverse polarity and forced supply of 24 V DC.
