Allen Bradley Modules 1768-L43S 1768L43S AB 1768 L43S COMPACTLOGIX L43 SAFETY PROCESSOR For new products
The Remote I/O communications module allows a SCANport product to look and act like a Remote I/O chassis when connected to a programmable controller. Data contained in the input/output image table is transferred between the programmable controller by the Remote I/O scanner, the same as with any Remote I/O chassis. You control the location of data transferred by setting the rack address and
starting group. You control the amount of data by setting the DIP switches on SW3. Important: Thecommunications module does not scale the data that is transferred. Consequently, all scaling of the data must be done in the controller. Refer to the user manual for your SCANport product for details on
device units. Important: The Remote I/O to SCANport conversion is asynchronous. Data sent to the adapter for transfer to the drive must be maintained until the drive has received data.DIP switches on SW3 determine how the data contained in the programmable controller I/O image table is used in the drive. Figure shows an I/O image table.
Related Product Recommendation:
For the requested packet interval, enter the number of milliseconds desired between each I/O message
between the ControlLogix processor and the 1203-CN1. The 1203-CN1 can handle a packet interval as
low as 5 milliseconds; therefore, make sure that this value is set to at least Click the "Finish" button to
complete the configuration of the I/O connection in RSLogix 5000. At this point, download your configuration to the ControlLogix processor, then exit RSLogix 5000. To actually schedule the I/O, you will need to start RSNetWorx for ControlNet. Once RSNetWorx starts, go online to the ControlNet network
containing the ControlLogix chassis and 1203-CN1 being configured. Turn on the "Enable Edits" check box, then save the network. This causes the I/O connection created in RSLogix 5000 to be scheduled in the ControlLogix processor. After a few seconds, the I/O LED on the ControlLogix processor and the module LED on the 1203-CN1 should stop blinking and remain green. If they do not, it could indicate a number of I/O-related problems
1756-L55M14/A 1756-L55/A, 1756-M14/A Logix5555 Processor, 3.5 MB memory, Series A AB
1756-L55M16/A 1756-L55/A, 1756-M14/A Logix5555 Processor, 7.5 MB memory, Series A AB
1756-L61/A Logix5561 Logix5561 Processor - 2MB AB
1756-L61/B Logix5561 Logix5561 Processor - 2MB AB
1756-L62/A Logix5562 Logix5562 Processor - 4MB Memory AB
1756-L62/B Logix5562 Logix5562 Processor - 4MB Memory AB
1756-OB16E/A Digital Fused Output Module - Series A AB
1756-PA72/A 1756-PA72 Power Supply - Series A AB
1756-PA72/B 1756-PA72 Power Supply - Series B AB
1756-PA72/C 1756-PA72 Power Supply - Series A AB
1761-CBL-PM02 Program Storage Device Cable AB
1761-L32BBB MicroLogix 1000 Unit AB
1762-IQ16 16PT 24VDC Power Supply Module AB
1762-MM1 MicroLogix Memory Module AB
1762-MM1RTC MicroLogix Memory and Real-Time Clock Module AB
1762-OF4 Analog Output Module AB
1762-OW16 16PT VAC/VDC Relay Output AB
1762-RTC MicroLogix Real-Time Clock Module AB
1764-24BWA MicroLogix 1500 Base Unit AB
1764-LRP Processor AB
1764-LSP Processor Module AB
1766-L32BWA Micro Logic Relay Output AC Power AB
1769-ECR Right End Cap AB
1769-IF4 Analog Input Module AB
1769-IQ16 Digital Input Module AB
