Allen Bradley 1442-PS-0803M0010N 1442 PS 0803M0010N AB 1442PS0803M0010N

Allen Bradley 1442-PS-0803M0010N 1442 PS 0803M0010N AB 1442PS0803M0010N

Product Description:

All drives come equipped with a fault LED. When the fault LED is illuminated it is an indication a fault condition exists. Refer to page 2-3 for the location of the fault LED. Once the fault is properly cleared the LED will return to an off state. Diagnostics As can be seen in Figure 2.3, there are two indicators

provided to display the drive’s status condition. The DC Bus Charge Indicator is a neon bulb that will be illuminated when power is applied to the drive. The Fault Indicator is an LED that will be illuminated if a drive fault condition exists. Refer to details on How To Clear a Fault, below.How To Clear a Fault

Important: Resetting a fault will not correct the cause of the fault condition. Corrective action must be taken prior to resetting the fault. To clear a fault perform one of the following:Cycle power to the drive. Cycle the stop signal to the drive. Cycle the [Clear Fault] parameter.

Contact Information:

Email :sales@mooreplc.com
Q Q: 2851195450
Skype: miyazheng520
Mobile:86-18020776792 ( what's app )

Related Product Recommendation:

All parameters required for any given drive function will be contained within a group, eliminating the need to changegroups to complete a function.To help differentiate parameter names and display text from
other text in this manual, the following conventions will be used – Parameter Names will appear in

[Brackets] – Display Text will appear in “Quotes.” Parameter information in this chapter is presented for users who have a Human Interface Module (HIM) installed. For those users without a HIM installed, the
drive can be operated using the factory default values for each parameter or parameter values can be

changed through the serial port. FUNCTION INDEX The Function Index shown provides a directory of various drive functions. The Page Number will direct you to the parameters associated with each function.
