Product Description:

Appendix B provides information about the Block Transfer messages supported by the Remote I/O communications module. In this appendix, you will read about the following: Block transfer status word.
Setting up data files for block transfer messages.Examples of block transfer messages. Block transfer

quick reference. Important: This appendix provides detailed examples of block transfer messages. For information about block transfer messages, also refer to Chapter 5.Chapter 1 provides an overview of the
Remote I/O communications module (1203-GD1 module, 1203-GK1 module, and 1336-GM1 board). In

this chapter, you will read about the following:Function of the module.Features of the module. Compatible SCANport products and programmable controllers. Parts and hardware of the module. Steps for setting up the module.Required tools and equipment.Description of the Remote I/O Communications Modules

The Remote I/O communications module is an optional interface designed to provide a direct, digital link between an AB programmable controller and any one AB SCANport product. A module is required for each product that you want to connect to Remote I/O. There are three types of

Remote I/O communications modules
