| Place of Origin | sweden |
| Brand Name | ABB |
| Certification | CO.CQ |
| Model Number | RDCU-12C |
RDCU-12C ABB ASC800 control board RDCU-12C 3AUA0000036521 ABB RDCU-12C
Email: miya@mvme.cn
Brand: ABB
TYPE: RDCU-12C
The shields of the I/O cables should be grounded to the chassis of the cubicle as close to the RDCU as possible. Use grommets at all cable entries. Handle fibre optic cables with care. When unplugging fibre optic cables, always grab the connector, not the cable itself. Do not touch the ends of the fibres with bare hands as the fibre is extremely sensitive to dirt. The maximum long-term tensile load for the fibre optic cables included is 1 N; the minimum short-term bend radius is 25 mm (1”).
The RDCU is powered through connector X34. The unit can be powered from the power supply board of the inverter (or IGBT supply) module, provided that the maximum current of 1 A is not exceeded. The RDCU can also be powered from an external 24 V DC supply. Note also that the current consumption of the RDCU is dependent on the optional modules attached. (For current consumption of optional modules, see their respective user manuals.)
| Schneider | 140NOM21200 | GE | 323A2357P4 FUSE (15A) |
| Schneider | 170ADO35000 | GE | 323A2396P155 FUSE 5A |
| Schneider | 170INT11003 | B&R | 3BP150.41 |
| Schneider | 416NHM30032 | B&R | 3PS754.9 |
| ABB | AO810 | B&R | 7BP704.0 |
| ABB | AO810V2 | B&R | 7AI774.70 |
| ABB | CI801 | B&R | 7DM465.7 |
| ABB | CI830 | B&R | 7CP474.60-1 |
| ABB | DI810 | B&R | 7DI-32B |
| ABB | DO810 | B&R | ECPSA2-0 |
| ABB | DO820 | B&R | ECR165-0 |
| ABB | RLM01 | B&R | 7IF321.7 |
| ABB | AI836 | B&R | ECNT44-0 |
| ABB | AI836A | B&R | ECE243-1 |
| ABB | AO811 | B&R | ECPA42-0 |
| ABB | AO810V3 | B&R | ECA244-0 |
| ABB | CI859 | B&R | 7AC911.9 |
| ABB | CI888 | B&R | ECCP70-01 |
Shipping: We ship World Wide by regular post unless instructed to ship by other modes.
We can ship by DHL,UPS,FEDEX,ARAMAX,TNT,etc.
Our regular Handling time is 2-3 working days.
We have a large inventory of Bailey Infi 90 DCS equipment that has come from the shut down of the Penrice Soda factory. We will be listing this all shortly, however if there is something you know you want please do not hesitate to contact me.
