PC834-107-N |Pacific Scientific | Danaher Motion Pacific Scientific Servo Drive
About the Product
The PCE830/40 drives are designed for operation in a cabinet. Follow these installation instructions:
● Mount the drives vertically inside a cabinet on a flat, solid, electrically conductive, mounting surface connected to PE (protective earth ground) and capable of supporting the weight of the unit.
● Remove the paint on the mounting surface over an area extending at least 12 mm (0.5”) from the mounting bolts to achieve good electrical connection over a large area between the drive and grounded mounting surface.
● Install conductive clamps near the drive on the mounting panel (ground plane) for electrically connecting the outer shield of certain cables (defined below) to the panel. The conductive clamps can also be attached to PE on the front of the drive. Remove about 10mm (0.5”) of the outer jacket of these cables where the clamp will be exposed to the braided shield before inserting under the clamp and tightening. The length of the cable between the drive connection and the clamp should be as short as possible (not exceeding 0.6 meters (two feet)). If a ground plane is available at the other end of these cables, use a conductive clamp at that end to connect the shield to that ground plane as well.
● Provide a minimum unobstructed space of 100 mm (4”) above and below the drive. With convection cooling, provide 40mm (1.6”) free space on either side of each unit. With forced air cooling, provide 25mm (1") free space on the side of the drive with the heat sink.
● Insure the environment within the cabinet meets the requirements defined in the Specifications section.
