100% test ABB SDCS-PIN-51 3BSE004940R1 (by DHL or EMS 90days Warranty)

Miya(manager)

Email:miya@mvme.cn

Skype:miyazheng520

QQ :2851195450

Tel:0592-5087576

     86-18020776792

Moore LIMITED is committed to improve the level of world automation parts supply. No matter what the customer is, no matter how rare the accessories we need, we can always connect the customer with their desired product. It is a wide range of industrial automation spare parts for customers

around the world.

Has sold 68,268,313 stock parts for customers .

More than a thousand excellent manufacturers for you to choose10 million inventory, adequate supply

We are achieving faster speed.

SDCS-PIN-51 3BSE004940R1

In general the SDCS-PIN-20xB board has the same features as its predecessors (SDCS-PIN-20xA/20x or SDCS-PIN-2x). - It is used for all DCS converters Module sizes C1 (≥ 100A), C2 and C2b regardless of software version and function (armature or field supply). - Converters equipped with the SDCS-PIN-20xB/20xA/20x boards can be identified by serial number. Every serial number is divided into two parts by a letter. With the SDCS-PIN-20xB/20xA/20x the serial number looks like 1234567B1234567. For the SDCS-PIN- 2x an A is used. - There are two types of SDCS-PIN-20xB boards: • SDCS-PIN-205B for converters with a incoming voltage of 400V/500V • SDCS-PIN-206B for converters with a incoming voltage of 600V - The advantage of the

SDCS-PIN-20xB/20xA/20x is the replace- ment of 6 other boards plus a small RC network. Thus the spare part handling becomes easier.

On the SDCS-PIN-20xB resistors are used for hardware coding of the module, zero current detection and current scaling. In a new converter the resistors are already cut according to application. If the SDCS-PIN-20xB board is used as spare part all resistors are still uncut. The resistors have to be cut according to the table ‘Set- tings of the SDCS-PIN-20xB board’ as described in the manual Technical Data.

The incoming AC voltage is connected to the SDCS-PIN-20xB board via integrated fuses. The snubber circuit (RC network) is in- tegrated as well and connected in parallel to the thyristors. This configuration leads to lower losses thus to a higher efficiency of the converter. Before larger converters had external RC networks. These are no longer needed.
