IC697CMM741     IC697CMM741     IC697CMM741

The Ethernet Controller is a member of the family of IC651 Factory LAN hardware and software products.

The Factory LAN family of products provides high performance solutions for interconnecting automation controllers and

for integrating them into multi-vendor networks.
The Ethernet Controller plugs into a single slot in an IC697 PLC rack and provides an 802.3-standard 15-pin D-connector for

attachment of a user-supplied AUI (Attachment Unit Interface) or transceiver cable.

The AUI cable connects to a user-supplied transceiver that is directly connected to the 10Μbps Ethernet network cable.

The transceiver must be 802.3-compatible and must have the SQE option enabled.
Transceivers are commercially available to operate on a variety of 10Μbps media including thickwire coaxial cable (10Base5),

ThinWire coaxial cable (10Base2), twisted pair (10BaseT), fiber optic (10BaseF), and broadband cable (10Broad36).
The Ethernet Controller is designed so the communications protocols which operate above the
Ethernet data link layer are implemented in software. This permits the user to choose between two* alternative communication

protocols by downloading the Ethernet Controller with the applicable

Communications Software:
TCP/IP-Ethernet Communications Software - Communicate with host computers and/or

MS-DOS or WIndows Programmer using proprietary SRTP over a 4-layer TCP/IP (Internet) protocol stack;

requires either a Local or Network Factory LAN System Manager (GSM) for configuration and downloading of Ethernet Controller software.

MMS-Ethernet Communications Software - Communicate with host computers and/or MS-DOS or Windows Programmer

using MMS (Manufacturing Message Specification - ISO 9506) on a 7-layer OSI protocol stack;

requires GSM for configuration and downloading of Ethernet Controller software. Figure 1 shows the general relationship between the Ethernet Controller,

the local and network GSMs, and the MS-DOS or Windows Programming Software on Ethernet station.
