PL10 0 811 405 061 0811405061 BOSCH REXROTH Rule Card Mint

PL10 0 811 405 061 0811405061 BOSCH REXROTH Rule Card MINT

Product Details

Features

 Directly operated servo solenoid valve NG10, with control piston and sleeve in servo quality

 Actuated on one side, 4/4 fail-safe position when switched off

 Control solenoid with integral position feedback and electronics for position transducer (Lvdt DC/DC)

 Suitable for electrohydraulic controllers in production and testing systems

 For subplate attachment, mounting hole configuration to ISO 4401-05-04-0-94

 Subplates as per catalogue section RE 45055 (order separately)

 Line sockets to DIN 43560-AM2 Solenoid 2P+PE/M16x1.5, position transducer 4P/Pg7 in scope of delivery, see catalogue section RE 08008

 External trigger electronics (order separately) Electric amplifier for standard curve “L” 0 811 405 061, see catalogue section RE 30041

 Electric amplifier for non-linear curve “P”40% – 0 811 405 067, see catalogue section RE 30040

Technical data

Construction: Spool type valve, operated directly, with steel sleeve

Actuation: Proportional solenoid with position control, external amplifier

Type of mounting: Subplate, mounting hole configuration NG10 (ISO 4401-05-04-0-94)

Installation position: Optional

Ambient temperature range: –20…+50°C

Vibration resistance, test condition: Max. 25 g, shaken in 3 dimensions (24h)
