M - FAST SFP-MM/LC HIRSCHMANN SFP Fiberoptic Fast Ethernet Transceiver MM

M-FAST SFP-MM/LC HIRSCHMANN SFP Fiberoptic Fast-Ethernet Transceiver MM with LC connector

Product Details

Technical Specifications

Network size - length of cable

Multimode fiber (MM) 50/125 µm: 0 - 5000 m (Link Budget at 1310 nm = 0 - 8 dB; A=1 dB/km; BLP = 800 MHz*km)

Multimode fiber (MM) 62.5/125 µm: 0 - 4000 m (Link Budget at 1310 nm = 0 - 11 dB; A = 1 dB/km; BLP = 500 MHz*km)

Power requirements

Operating Voltage: power supply via the switch

Power consumption: 1 W

Software

Diagnostics: Optical input and output power, transceiver temperature

Ambient conditions

MTBF (Telecordia SR-332 Issue 3) @ 25°C: 514 Years

Operating temperature: 0-+60 °C

Storage/transport temperature: -40-+85 °C

Relative humidity (non-condensing): 5-95 %

Mechanical construction

Dimensions (WxHxD): 20 mm x 18 mm x 50 mm

Weight: 30 g

Mounting: SFP slot

Protection class: IP20

Mechanical stability

IEC 60068-2-6 vibration: 1 mm, 2 Hz-13.2 Hz, 90 min.; 0.7 g, 13.2 Hz-100 Hz, 90 min.; 3.5 mm, 3 Hz-9 Hz, 10 cycles, 1 octave/min.; 1 g, 9 Hz-150 Hz, 10 cycles, 1 octave/min

IEC 60068-2-27 shock: 15 g, 11 ms duration, 18 shocks

EMC interference immunity

EN 61000-4-2 electrostatic discharge (ESD): 6 kV contact discharge, 8 kV air discharge

EN 61000-4-3 electromagnetic field: 10 V/m (80-1000 MHz)

EN 61000-4-4 fast transients (burst): 2 kV power line, 1 kV data line

EN 61000-4-5 surge voltage: power line: 2 kV (line/earth), 1 kV (line/line), 1 kV data line

EMC emitted immunity

EN 55022: EN 55022 Class A

FCC CFR47 Part 15: FCC 47CFR Part 15, Class A

Approvals

Safety of information technology equipment: EN60950

Hazardous locations: depending on deployed switch

Shipbuilding: depending on deployed switch
