| Place of Origin | GERMANY |
| Brand Name | BOSCH REXROTH |
| Certification | CO.CQ |
| Model Number | 5610102050 |
5610102050 BOSCH REXROTH PRESSURE REGULATOR
| Brand/Manufacturer | REXROTH / GERMANY |
| Part Number |
5610102050 |
| Alternate Part Number |
5610102050 |
| Description | PRESSURE REGULATOR |
| Dimennsions | 11.2cm x 11.5cm x 9.8 cm |
| Weight | 2.0kg |
Product Details
Specifications
Version: Poppet valve
Control: Analog
Certificates: CE declaration of conformity
Ambient temperature min./max.: +5°C / +50°C
Medium temperature min./max.: +5°C / +50°C
Medium: Compressed air
Max. particle size: 50 µm
Max. oil content of compressed air: 0.1 mg/m³
Qn: 800 l/min
Mounting orientation: vertical
Hysteresis: 0,04 bar
DC operating voltage: 24 V
Voltage tolerance D: -20% / +20%
Permissible ripple: 5%
Max. power consumption: 0.2 mA
Protection class: IP54
Compressed air connection input: G 1/4
Compressed air connection output: G 1/4
Compressed air connection, exhaust: G 1/4
Weight: 2 kg
About BOSCH REXROTH
Clearing snow at -0° F and harvesting corn at +100° F; manufacturing components with 1000th mm accuracy; moving slice gates that weigh several metric tons and the most famous stages in the world. We move everything.
As a global partner, Bosch Rexroth supports mechanical and plant engineering efforts around the world with its cutting-edge technology and unique industry knowledge. More than 29,500 associates across the globe are developing tailored, safe and resource-friendly solutions. Our innovations deliver multi-dimensional enhancements for machine manufacturers and end users. For example, they help to reduce harmful carbon dioxide emissions while simultaneously raising productivity.
Above all, we make it easy to use cross-technology solutions by means of predefined functions and integrated engineering tools.
