HMIGXU3512 Schneider Touch Screen 2 Serial Ports 1 Ethernet Port

Schneider HMIGXU3512 Touch Panel Screen 2 serial ports 1 Ethernet port embeddedRTC

⇒ Click here for good price HMIGXU3512

Product Details

Specifications

Main

range of product: Harmony Easy GXU

product or component type: Advanced touchscreen panel

display type: LCD touch screen

display colour: 65536 colours

display resolution: 800 x 480 pixels WVGA

display size: 7 inch

Complementary

backlight lifespan: 20000 hours

[Us] rated supply voltage: 24 V DC

software designation: Vijeo Designer Basic configuration software

memory description:

Internal, 48 MB for application

Internal DDR, 128 MB

Internal, 128 kB for backup

integrated connection type: USB type mini B; COM1 serial link: 9-way male SUB-D connector, RS232C; COM2 serial link: 9-way male SUB-D connector, RS422/RS485; USB type A

Ethernet 10/100BASE-TX

cut-out dimensions: 190 x 135 mm

Environment

quality labels: CE

ambient air temperature for operation: 0…50 °C

ambient air temperature for storage: -20…60 °C

IP degree of protection: IP65 (front panel)

Offer Sustainability

Sustainable offer status: Green Premium product

REACh Regulation: REACh Declaration

EU RoHS Directive: Pro-active compliance (Product out of EU RoHS legal scope); EU RoHS Declaration

Mercury free: Yes

RoHS exemption information: Yes

China RoHS Regulation: China RoHS declaration

Environmental Disclosure: Product Environmental Profile

Circularity Profile: End of Life Information
