IC693MDL742 GE Output Module
  • IC693MDL742  GE  Output Module
  • IC693MDL742  GE  Output Module

IC693MDL742 GE Output Module

Place of Origin USA
Brand Name GE
Certification CO.CQ
Model Number IC693MDL742
Product Details
Manufacture Year:
2020
Con 6DS1311-8AEtrol System:
IC693MDL742
Application:
Nuclear Power Plant
Lead Time:
In Stock
Description:
GE
Weight:
4lbs
High Light:

IC693MDL742

,

GE Output Module

Payment & Shipping Terms
Minimum Order Quantity
1
Price
inquiry
Packaging Details
new and original with factory sealed
Delivery Time
today
Payment Terms
T/T
Supply Ability
10 pieces a day
Product Description



IC693MDL742 GE Output Module



⇒ Click here for good price IC693MDL742



Brand/Manufacturer   GE/USA
Part Number

  IC693MDL742

Alternate Part Number   IC693MDL742
Description   MOTOR SERVO
Dimennsions

  3.5x13x13.5cm

Weight   0.3kg



Contact Us

Email: miya@mvme.cn (CLICK)

QQ: 2851195450

Tel: 86-18020776792(CLICK)

Skype:miyazheng520(CLICK)



Product Details

The GE Fanuc IC693MDL742 is a 12/24 volt DC Positive Logic 1 Amp Electronic Short Circuit Protection (ESCP) Output module. Made to work with the Series 90-30 PLC, this ESCPP module has a total of 16 output points. These points are arranged in two individual banks of eight. There is a common power output terminal shared by the points of each group. By design, this output module has positive logic characteristics. This means it sources current from either the user common or else the positive power bus, directing it to the load.



Among the load devices that are compatible with the output characteristics of this module are solenoids, indicators and motor starters. Output devices like these must be connected between the negative power bus and the module output. The user must supply external power to operate the field devices. On top of the ESCP module there are two rows of LED indicators. These show the ON/OFF status of each one of the output points. Each green LED corresponds to the relative output point. Row A1 has the LED indicators for outpoints points 1 to 8, while row B1 is for output points 9 to 16.



Centered between the two rows is a single red LED, labelled “F”. This is a tripped electronic short circuit protection indicator. Whenever any short circuit protection trip happens, this LED will turn on. The common signal for each group is monitored electronically. If a short circuit occurs in the power supply, the output points in that group will turn off and the red LED will turn on. Users must be aware that the protection does not prevent individual outputs from exceeding their ratings. It will only protect the board in the event of a short-circuited load. The module has two electronic short circuit protection circuits.

IC693MDL742  GE  Output Module 0
