IC693PWR322D GE Power Supply Module
⇒ Click here for good price IC693PWR322D
Brand/Manufacturer | GE/USA |
Part Number |
IC693PWR322D |
Alternate Part Number | IC693PWR322D |
Description | Power Supply Module |
Dimennsions |
38x36x5cm |
Weight | 1.32kg |
Contact Us
Email: miya@mvme.cn (CLICK)
QQ: 2851195450
Tel: 86-18020776792(CLICK)
Skype:miyazheng520(CLICK)
Product Details
The GE Fanuc IC693PWR322 is a 24/48 VDC standard power supply. The standard unit, which does not include a battery, is designed to work
off a nominal input of 12V DC or 48V DC and has a 30 watt output. This unit can be mounted in a standard power supply slot through any IC693
PLC baseplate. Although it is capable of maintaining all outputs (within specifications) with input voltages as low as 18VDC, it will not start with
initial input voltages of less than 21 VDC. This power supply provides three separate outputs. These are +5VDC, +24VDC relay output for powering
circuits on any IC693 relay output module and +24VDC Isolated power for Input modules.
When using this power supply, users can calculate the power requirements specific to their application. To do this, you first need to determine
the total output load by checking the specs listed in the IC693 PLC Installation and Hardware Manual. This will show the specifications for
individual modules. The total output load should be multiplied by 1.5 to determine input power value. To calculate the input current requirement,
divide the input power by the operating source voltage. As the operating source voltage may vary, you should use the lowest measured or
estimated input voltage to determine the maximum input current. Operators who are making this calculation should also allow for start-up surge
current requirements and allow a margin of 10-20% for variation.
