2MLQ-TR4B HONEYWELL Transistor Output Module
| Product Description |
|
The Honeywell 2MLQ-TR4B is a 32-point transistor digital output module in the MasterLogic-200 family of PLC I/O modules. It is the “source type”
version (i.e. outputs source current to the load). It is designed for industrial automation systems, driving low-power loads such as indicator
lamps, small solenoids, solid state relays, etc. It features photo-coupler isolation for each output (or group) to provide protection
and signal integrity. It connects via a 40-pin connector and mounts in the MasterLogic-200 rack/base.
|
| More Technical Data |
| Output Type |
Transistor Output, Source Type |
| Number of Output Points (Channels) |
32 points |
| Rated Load Voltage |
DC 12 V / 24 V |
| Operating/Load Voltage Range |
DC 10.2 V to 26.4 V |
| Frequently Asked Questions |
|
1. What is the Honeywell 2MLQ-TR4B?
The Honeywell 2MLQ-TR4B is a 32-point digital output module featuring source-type transistor outputs. It is designed for use with the
MasterLogic-200 PLC system and is suitable for controlling low-power devices such as relays, indicator lights,
and small motors in industrial automation applications.
2. What is the external connection method?
The module uses a 40-pin connector for external connections. Ensure proper cable size and
secure connections to maintain reliable operation.
3. What is the power supply requirement?
The module requires a stable DC 12/24V power supply with minimal ripple (≤4V peak-to-peak) to
ensure consistent performance.
4. What is the operating temperature range?
The module operates within a temperature range of -20°C to 65°C.
|
