1006/2/1 HONEYWELL Control module
| Product Description |
|
The Honeywell 10006/2/1 Diagnostic and Battery Module (DBM) is part of the FSC (Fail-Safe Controller) series from Honeywell. Its function is to
provide diagnostics and battery backup monitoring for the FSC system.Front-panel display for fault messages (type of fault, rack number,
position) so diagnostics are easier.Real-time clock; allows viewing of date/time, system voltages, battery voltage, and internal
temperatures.Designed for use in safety/instrumented systems and large process installations (chemicals,
oil & gas, etc) where fault detection and uptime are critical.
|
| More Technical Data |
| Part Number / Model |
10006/2/1 (sometimes suffix “08801*” for improved noise immunity) |
| Product Type |
Diagnostic & Battery Module (DBM) |
| Software Version Compatibility |
≥ 2.90 for FSC system. |
| Weight |
~0.24 kg (~240 g) in one listing. |
| Frequently Asked Questions |
|
Q1: What is the main purpose of the DBM (10006/2/1)?
A: Its primary role is as a diagnostic interface and battery backup module for Honeywell’s FSC controller system. It helps detect faults, monitor system health (voltages, temperatures), and preserve critical data during power outages.
Q2: What kind of faults can it detect/display?
A: It can detect and display faults in analog inputs (AI), digital inputs (DI), analog outputs (AO), digital outputs (DO), central part faults (CP),
high/low temperature conditions (EH/EL), HBD (horizontal bus driver) faults (HB) and others.
Q3: What are the power requirements?
A: It requires 5 Vdc supply and draws around 300 mA typical. Ripple content must be <50 mV p-p.
Q4: What backup capacity does the battery provide?
A: The onboard battery capacity is around 0.5 Ah (for backup of RAM/configuration in event
of power failure).
Q5: Is the module still supported / current?
A: The module is part of Honeywell’s FSC system ecosystem (which is older). According to Honeywell site
listing of parts, the 10006/2/1 appears under legacy parts “FSC” category. In practice you should
verify with Honeywell or authorised distributor if it is still recommended
for new systems or if upgrade paths exist.
|
