Bently Nevada 3500 System
>
330180-X2-05 MOD: 163358-02 Bently Nevada 3300 XL Proximity Sensor for High-precision Vibration and Position Monitoring
330180-X2-05 MOD: 163358-02 Bently Nevada 3300 XL Proximity Sensor for High-precision Vibration and Position Monitoring
  • 330180-X2-05 MOD: 163358-02 Bently Nevada 3300 XL Proximity Sensor for High-precision Vibration and Position Monitoring
  • 330180-X2-05 MOD: 163358-02 Bently Nevada 3300 XL Proximity Sensor for High-precision Vibration and Position Monitoring
  • 330180-X2-05 MOD: 163358-02 Bently Nevada 3300 XL Proximity Sensor for High-precision Vibration and Position Monitoring

330180-X2-05 MOD: 163358-02 Bently Nevada 3300 XL Proximity Sensor for High-precision Vibration and Position Monitoring

Product Details:
Place of Origin: USA
Brand Name: Bently Nevada
Certification: CO.CQ
Model Number: 330180-X2-05 MOD: 163358-02
Detail Information
Place of Origin:
USA
Brand Name:
Bently Nevada
Certification:
CO.CQ
Model Number:
330180-X2-05 MOD: 163358-02
Product Series:
Bently Nevada 3300 XL Proximitor Series
Nominal Sensitivity:
7.87 V/mm (200 MV/mil) For Standard 8mm Configurations
Input Power Requirements:
Requires Stable -17.5 Vdc To -26 Vdc Supply Rail
Target Material Standard:
AISI 4140 Steel (retains Full API 670 Compliance When Gapped)
Highlight:

High Light

Highlight:

API 670 Compliant: Meets global industry oil & gas machinery standards.

,

Eddy Current Signal Processing: Precise non-contact dynamic displacement tracking.

,

High Interchangeability: Complete field-swapping without recalibration errors.

Trading Information
Minimum Order Quantity:
1
Price:
inquiries
Packaging Details:
new and original with factory sealed
Delivery Time:
2-3 work days
Payment Terms:
T/T
Supply Ability:
requires
Product Description
330180-X2-05 MOD: 163358-02 Bently Nevada 3300 XL Proximity Sensor
Engineered with an advanced eddy current detection circuit, the 330180-X2-05 MOD: 163358-02 Proximitor Sensor delivers precise analog output for both static position and dynamic vibration monitoring. It eliminates the critical technical pain points of signal drift and scale-factor error caused by unmatched hardware components, offering 100% complete field interchangeability. This makes it the definitive industry standard for high-reliability machinery protection systems on critical fluid-film bearing equipment like steam turbines, high-speed compressors, and large process pumps.
Engineer's Note
"When retrofitting or deploying the 330180-X2-05 sensor containing modification code `163358-02`, you must verify your total physical system loop length before applying power. Suffix configurations like `12` or `52` require strict matching with corresponding 1.0-meter or 5.0-meter probe/cable lengths. Failing to align the sensor's internal tuning circuitry with the exact physical length of the extension line will alter the system's baseline bias voltage (normally -9 Vdc at a 50-mil gap) and completely skew your machine's vibration diagnostics."
Custom Product FAQ
Q: What exactly does the "MOD: 163358-02" label indicate on this 330180 Proximitor?
A: The `MOD: 163358-02` marking indicates an engineered factory modification or tailored hardware calibration baseline. It ensures the internal oscillator-demodulator circuit matches explicit response parameters required by specified control system loops or alternative target structures without degrading linear accuracy.
Q: Can I use this 330180 sensor interchangeably with standard 5mm and 8mm probes?
A: Yes. The 3300 XL Proximitor series is universally backward-compatible and engineered to accept non-contacting 3300-series 5mm probes as well as standard 3300 XL 8mm probes and extension lines.
Q: What is the risk if my power supply drops more positive than -23.5 Vdc when using barriers?
A: Operating the sensor at voltages more positive than -23.5 Vdc restricts the maximum internal signal amplification headroom. This reduction shortens the overall active linear range of your proximity transducer system, causing premature signal clipping during high-amplitude shaft vibration events.
