1203-CN1 Bulletin 1203-CN1 ControlNet Communications Module Allen Bradley CPU

Allen Bradley Modules 1203-CN1 Bulletin 1203-CN1 ControlNet Communications Module Reasonable price

Product Description:

 A ControlLogix processor, firmware version 4.35 or later.
 A ControlLogix ControlNet bridge, firmware version 1.19 or later.

 RSLinx software, version 2.10.137 or later.

Related Product Recommendation:

Product's Character:

After starting RSLogix 5000 and either starting a new project or opening an existing project, make sure
that you are OFFLINE with the ControlLogix processor. I/O configuration is only available when offline.
If you have not already defined the contents of your ControlLogix chassis under your project's "I/O
Configuration" folder, you will need to define the ControlNet bridge module at a minimum. Use the right
mouse button to click on the "I/O Configuration" folder, then choose "New Module" from the pop-up menu.
From the dialog box that appears, choose the ControlNet bridge of the type (1756-CNB or 1756-CNBR)
and series that you are using. In the next screen, you will need to name the ControlNet bridge and
indicate its position in the ControlLogix chassis (slot 0 is the leftmost).

The use of the product:
