Product Description:

Caused by the direct electrical connection with the output, the varistor for demagnetization of inductive
loads (see figure above) is also in effect at the input.Therefore, the voltage difference between UP5 and
the input signal must not be greater than the limit voltage of the varistor.The limit voltage of the varistor is ca. 36 V. This means,that if UP5 = 24 V, the input signal voltage must be between -12 V and +30 V. If UP5 = 30 V, the input voltage has to be within -6 V and +30 V

Related Product Recommendation:

Product's Character:

Input currents which exceed the measuring range cause an overflow error message. If the measured value is below the range, an underflow error message is generated.The input impedance is ca. 330 Ω. The current input has a self-protecting mechanism. If the input current gets too high, the shunt is switched off and the value for range overflow is generated. About every second, the unit tries
to switch on the shunt again. In this way the correct measurement will succeed after the current has reached a normal value again.The trigger of the self-protecting mechanism is displayed by the red LED Ovl. as long as the overload is present. In the PLC system an error message is then stored.
