ABB Module 07KT98 GJR5253100R0270 ABB 07KT98 PROFIBUS DP High reliability

ABB Module 07KT98 GJR5253100R0270 ABB 07KT98 PROFIBUS DP High reliability

Product Description:

PROFIBUS-DP PROCESS FIELDBUS -DECENTRAL PERIPHERYDP master (class 1) normal bus master
DP master (class 2) commissioning device DP slave (DPS) I/ module DPV1 guidelineforextendedfunctions for PROFIBUS-DP PNO PROFIBUS Nutzer-Organisation
(user organization) Standardization EN 50170, DIN 19245 Part 1, DIN 19245 Part 3, DPV1 Basics
PROFIBUS-DP is intended for fast data exchange in the field area. Here, central control units (e.g. PLC/PC) communicate with decentralized field devices like I/O, drives and valves via a fast serial connection. The data exchange with the decentralized modules is mainly performed cyclically.
The communication functions, required for data exchange,are defined by the PROFIBUS-DP basic functions,in accordance to EN 50170. For parametrization

Related Product Recommendation:

Product's Character:

The condition of the PROFIBUS coupler is indicated with
the 4 status LEDs.
After power ON the coupler initializes a self-test. If this
test was successful, the yellow READY LED goes ON.
Otherwise the LED starts flashing and aborts the further
initialization. If the LED remains OFF, the coupler is defective.
In the course of initialization, the RUN LED is OFF for the
first time. The LED is only activated after configuration
data has been sent to the coupler and the operating mode
of the coupler was set. If the operating system of the coupler
detects a parameterization or a configuration error,
the green RUN LED flashes non-cyclically. If this LED
flashes cyclically, the coupler is ready for communication,
but the communication is not active yet. In case of an
active communication, the RUN LED lights continuously.
The red ERROR LED indicates errors on the PROFIBUS
interface.
