ABB Module CI532V01 3BSE003826R1 CI532V01 Bus Card Communication Interface superior quality product

ABB Module CI532V01 3BSE003826R1 CI532V01 Bus Card Communication Interface superior quality product

Product Description:

Due to the direct connection to the output, the demagnetizing varistor is also effective at the input when disconnecting inductive loads (see figure). This is why the difference between UPx and the input signal may not exceed the clamp voltage of the varistor. The varistor limits the voltage to approx. 36 V. Following this, the input voltage mustrange from - 12 V to + 30 V when UPx = 24 V and from - 6 V to + 30 V when UPx = 30 V.When all 8 channels of the group are used as inputs and terminal UPx is not wired-up, there are no restrictions to the input signals. In this case, the input voltage can range from - 30 V to + 30 V. The following figure shows the circuit arrangement of a digital input/output

Related Product Recommendation:

Product's Character:

Number of channels per unit 32 transistor-outputs Division of channels in groups 4 groups with 8 channels each, channels An,00...An,07 and An,08...An,15 channels An+1,00...An+1,07 and An+1,08...An+1,15 Reference potentials for outputs ZP0, ZP1, ZP2 and ZP3 Voltage supply for outputs UP0, UP1, UP2 and UP3 Electrical isolation group from group, all groups from the rest of the unit
Signalization of output signals one yellow LED per channel, LED activated according to the input signal
Output current nominal value 500 mA at L+ = 24 V max. value 4 A total current for each group
leakage current at 0 signal

The use of the product:
