ABB Module DAPC100 3ASC25H203 ABB DAPC100 SERVICE LINE Super quality products
Product Description:
The technical specifications of the inputs are the same with the other digital inputs, but with the following
exception: Caused by the direct electrical connection with the output, the varistor for demagnetization of inductive loads (see figure above) is also in effect at the input. Therefore, the voltage difference between UP5 and the input signal must not be greater than the limit voltage of the varistor.The limit voltage of the varistor is ca. 36 V. This means,that if UP5 = 24 V, the input signal voltage must be between -12 V and +30 V. If UP5 = 30 V, the input voltage has to be within -6 V and +30 V. If all of the 8 channels of the group are used as inputs,and if in addition the UP5 terminal is left unconnected, no restrictions exist for the inputs. The input signal voltages then may be within -30 V and +30 V.There is no restriction for the input/output group concerning its safety against reversed polarity.
Related Product Recommendation:
|
Product's Character:
Features of the digital inputs/outputs:The 8 digital inputs/outputs are arranged in one group.The group as a whole is electrically isolated from the rest of the device.The inputs/outputs can be used individually as input,output or re-readable output. If the terminals are used as digital inputs, the input signal delay can be configured to 7 ms (default) or to 1 ms. The configuration is performed by setting certain
bits in the system constant KW 85,01 as follows: If the terminals are used as digital outputs, the output
signals "1" are individually monitored by the re-readable input. If the output status is wrong, an overall error message is generated for the involved output group.The error is displayed by the red LED Ovl. and by errorflags of the PLC then. The error could have been caused by overload, shortcircuit
or missing supply voltage UP5/ZP5.The technical specifications are the same as with the
other digital inputs and outputs.
The use of the product:
1.Customer service in 1-4 hours. If there's any question, please contact with our sales.
2.Experienced technichal support team.
3.365 days warranty for all the goods from us.
1. Q: Do you provide warranty for the goods?
A: Yes, we provide warranty for all the goods from us.
2. Q: Could Moore provide technology support?
A: We're in this field more than 12 years. If there's any problem, please contact with us,we'll provide suggestion from our engineer to help you solve problem.
3. Q: Does Moore keeps goods in stock or only trading?
A: We have large warehouse for goods. Keep lots of goods in warehouse, so could promise fast delivery.
