ABB Module DSTA131 57120001-CV ABB DSTA131 57120001-CV ABB DSTA 131 BOARD DSTA effective service
Product Description:
Use of analog inputs as digital inputs Several (or all) analog inputs can be configured as digital
inputs. When doing so, they evaluate input voltages higher than ca. +7 V as signal 1. The input impedance in this operating mode is about 4 kW. Terminal M is the reference
potential. The input signal delay is 7 ms. It cannot be configured. The inputs are not electrically isolated.The 07 KT 94 unit linearizes the Pt100 characteristic. Temperatures that exceed the measuring range cause the overflow numerical value of +32767. If the measured value is below the range, the underflow numerical value of -32767 is set. In case of a detected open-circuit the numerical value of
+32767 is set. If the sensor is short-circuited, the numerical value of -32767 is set.
If the open-circuit or short-circuit monitoring is configured, the detected error is displayed by the red LED Ovl as long as it is present. In the PLC system an error message is stored (FK4, error number 9).
In order to avoid error messages with unused analog inputs, it is useful, not to configure this channels for Pt100.
