ABB Module ICSE08B5 FPR3346501R1012 ABB ICSE08B5 Remote Analog Input Module long life

ABB Module ICSE08B5 FPR3346501R1012 ABB ICSE08B5 Remote Analog Input Module long life

Product Description:

Please observe in particular: The earthing measuresThe handling of the electrically isolated input groups
The handling of the electrically isolated output groups The connection of shielded analog cables
The earthing of the switch-gear cabinet mains socket Connection of the supply voltage
The 24 V DC supply voltage is connected via a 5-pole detachable screw-type terminal block.
Attention: Plug and unplug terminal block only with power is off Please take also into consideration that supply voltages which are looped through are disconnected for the following devices when the plug is withdrawn. If higher currents are to be conducted without interruption possibility, the two wires for M have to be connected under the same terminal. The same applies for L

Related Product Recommendation:

Product's Character:

The connection to the CS31 system bus is made by means of a 3-pole detachable terminal block. Please observe:All of the AC31 devices, no matter whether they are master or slave devices, are connected with twistedpair bus line as follows: One core of the bus line is looped through via the BUS1 terminals of all devices to be connected to the CS31 system bus.The other core of the bus line is looped through via
the BUS2 terminals of all devices to be connected to the CS31 system bus. If the basic unit 07 KT 94 is located at the beginning or at the end of the bus line, the bus terminating resistor (120 W) has to be connected additionally between the BUS1 and BUS2 terminals.

The use of the product:
