ABB Module YXO116 4890024-LC ABB YXO116 4890024LC ASEA BROWN BOVERI affordable price

ABB Module YXO116 4890024-LC ABB YXO116 4890024LC ASEA BROWN BOVERI affordable price

Product Description:

IResolution in the PLC system: The measured values are converted with a resolution of
12 bits, i.e. 11 bits plus sign for voltage and 12 bits without sign for current. The ranges 0...5 V und ±5 V are converted with 10 bits plus sign.the output A 62,00 is only available for the counter. If the output is to use as a normal digital output, it has to Further details can be found in volume 2, chapter 5.1 "General
information for the use of analog inputs and outputs". In order to make sure, that unused input channels have a defined 0V level, they may be shorted to AGND. Unused inputs must be configured with "unused".
The relationship between the analog input signals and the converted numbers is illustrated in the following figures. be made sure, that the high-speed counter is not configured to the operating modes 1 or 2 (see also the chapter "High-speed counter").Features of the analog inputs:The 8 analog inputs are not electrically isolated.The resolution of the A/D converter is 12 bits. Analog signals are conducted in shielded cables (seeThe analog inputs can be configured individually in a lot of different operating modes (even as digital inputs). The configuration is performed by setting certain bits in the system constants KW 86,00 to KW 86,07 as follows

Related Product Recommendation:

Product's Character:

The red LED Ovl. goes out when the overloaded output is switched on again automatically.
The acknowledgement of the error message, i.e. the resetting of the error flags, is carried out according to chapter B4.8 (Appendix), Acknowledgement of error messages in the basic unit.The outputs are safe against reverse polarity and forced supply of 24 V DC. Use of the digital output signal at the terminal 46
(A 62,00) for the high-speed counter The output A 62,00 can be assigned to the internal highspeed
counter by configuration. If the counter is used in the operating modes 1 or 2 (up-counter), the output A 62,00 is only available for the counter. If the output is to use as a normal digital output, it has to
be made sure, that the high-speed counter is not configured to the operating modes 1 or 2 (see also the chapter "High-speed counter").
