Allen Bradley Module 1785-LT3 1785LT3 AB 1785 LT3 Series A PLC Interface Module

Product Description

Allen Bradley Modules 1785-LT3 1785LT3 AB 1785 LT3 Series A PLC

Product Description:

When the drive mounted HIM is supplied, it will be connected as Adapter 1 (see Adapter in Chapter 2) and visible from the front of the drive. The HIM can be divided into two sections; Display Panel and Control Panel. The Display Panel provides a means of programming the drive and viewing the various
operating parameters. The Control Panel allows different drive functions to be controlled. Refer to Figure and the sections that follow for a description of the panels.Important: The operation of some HIM functions will depend upon drive parameter settings. The default parameter values allow full HIM
functionality.HIM OPERATION When power is first applied to the drive, the HIM will cycle through a series of displays. These displays will show drive name, HIM ID number and communication status. Upon
completion, the Status Display will be shown. This display shows the current status of the drive (i.e. “Stopped,”“Running,” etc.) or any faults that may be present (“Serial Fault,” etc.). If the HIM software is Series A version3.00

Related Product Recommendation:

Product's Character:

Bulletin 1305 drive parameter data can be programmed and displayed using PLC’s, SLC’s or other logic controllers using an optional Bulletin 1203 Communication Module. The amount of information that can be transferred between the drive and controller is determined by the DIP switch settings on theCommunication Module. Table B.1 illustrates the dip switch settings for Bulletin 1203-GD1 (Remote I/O) communication modules. Dip switch settings for other communication modules will be similar. Refer
to the appropriate communication module user manual for details.Important: 1305 drives with firmware revisions FRN1.01 and FRN1.02 are not compatible with Bulletin 1203 Communication Modules. If connected, an error message will be indicated. The red fault status and amber SCANport status LED’s on the front of the module will flash simultaneously.
