Allen Bradley Modules 2711-B6C10 2711 B6C10 AB 2711-B6C10 SER C REV A FRN

Allen Bradley Modules 2711-B6C10 2711 B6C10 AB 2711-B6C10 SER C REV A FRN

Product Description:

All parameters required for any given drive function will be contained within a group, eliminating the need to changegroups to complete a function.To help differentiate parameter names and display text from
other text in this manual, the following conventions will be used – Parameter Names will appear in [Brackets] – Display Text will appear in “Quotes.” Parameter information in this chapter is presented for users who have a Human Interface Module (HIM) installed. For those users without a HIM installed, the
drive can be operated using the factory default values for each parameter or parameter values can be changed through the serial port. FUNCTION INDEX The Function Index shown provides a directory of various drive functions. The Page Number will direct you to the parameters associated with each function.

Related Product Recommendation:

Product's Character:

The name of the tag will reflect the name you assigned the earlier. The "C" sub-group contains the contents of the configuration assembly, which is not currently used in the 1203-CN1. The "O" subgroup contains one entry for each word of output data you configured, and the "I" sub-group contains one entry for each word of input data you configured. The "O" sub-group corresponds directly to output data for a PLC-5 described on page 5-2 of the 1203-CN1 user manual (i.e., for most common configurations, word 0 is the logic command, word 1 is the speed reference, words 2 and 3 are the first pair of data links, etc.). The "I" sub-group is similar to the input data for a PLC-5, except that it is shifted by two words (i.e., word 2 is the logic status, word 3 is the speed feedback, etc.). Words 0 and 1 of the "I" sub-group represent network status data sent by the 1203-CN1 but not processed directly by the ControlLogix processor. At this point, I/O between the ControlLogix processor and the 1203-CN1 should be configured and running, and the meaning of the various I/O words should be understood. If you need further assistance in configuring I/O, please contact technical support.
