Allen Bradley 1442-PS-0505M0010N 1442PS0505M0010N AB 1442 PS 0505M0010N
Product Description:
Bulletin 1305 drive parameter data can be programmed and displayed using PLC’s, SLC’s or other logic controllers using an optional Bulletin 1203 Communication Module. The amount of information that can be transferred between the drive and controller is determined by the DIP switch settings on
theCommunication Module. Table B.1 illustrates the dip switch settings for Bulletin 1203-GD1 (Remote I/O) communication modules. Dip switch settings for other communication modules will be similar. Refer
to the appropriate communication module user manual for details.Important: 1305 drives with firmware
revisions FRN1.01 and FRN1.02 are not compatible with Bulletin 1203 Communication Modules. If connected, an error message will be indicated. The red fault status and amber SCANport status LED’s on the front of the module will flash simultaneously.
Contact Information:
Contact:Miya ( manager)
Email :sales@mooreplc.com
Q Q: 2851195450
Skype: miyazheng520
Mobile:86-18020776792 ( what's app )
