Product Description:

Manual, gives an overall description of the Bulletin 1305 Adjustable Frequency AC Drive (herein called “the drive”) and provides a listing of key drive options. Additionally, this chapter provides information on receiving and handling the drive. MANUAL OBJECTIVES The purpose of this manual is to provide

the user with the necessary information to install, program, start up and maintain the Bulletin 1305 drive. To assure successful installation and operation, the material presented must be thoroughly read and
understood before proceeding. Particular attention must be directed to the ATTENTION and Important

statements contained within. Chapter 2 provides instructions on how to mount and wire the drive. It also describes how to operate the drive without a Human Interface Module. Read the Motor Cable Length
section on pages 2-13 – 2-16, and the contact closure inputs information in the Control Terminal Block

descriptions on pages 2-19 – 2-21. Chapter 3 defines the display and control panel keys on the optional Human Interface Module. A flowchart is provided to guide the user through the key strokes of the various
menu levels.

Contact Information:

Email :sales@mooreplc.com
Q Q: 2851195450
Skype: miyazheng520
Mobile:86-18020776792 ( what's app )
